ड्राइविंग पॉलीयूरेथेन गोल बेल्ट व्यापक रूप से वस्त्र, सतह के किसी न किसी में उपयोग किया जाता है

Place of Origin China
ब्रांड नाम jiuna
प्रमाणन ROHS
Model Number Diameter 2mm-20mm
Minimum Order Quantity 10 rolls
Packaging Details Inner packing is plastic film .outer packing is carton
Delivery Time Within 5 working days After receipt of your deposit
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 100.000 meters per Month

नि: शुल्क नमूने और कूपन के लिए मुझसे संपर्क करें।

Whatsapp:0086 18588475571

WeChat: 0086 18588475571

स्काइप: sales10@aixton.com

यदि आपको कोई चिंता है, तो हम 24 घंटे ऑनलाइन सहायता प्रदान करते हैं।

x
उत्पाद विवरण
कठोरता 85ए-90ए रंग हरा
खिंचाव दर 1.5-3% तन्यता दर 0.7 एलबीएस-69 एलबीएस
सामग्री पीयू लंबाई 400m/रोल 300m/रोल 200m/रोल 100m/रोल 30m/रोल
एचएस कोड 3926909090 उत्पादन क्षमता लंबी अवधि की आपूर्ति
प्रमुखता देना

पु राउंड बेल्ट

,

ग्रीन राउंड बेल्ट

,

रफ राउंड पॉलीयूरेथेन ड्राइव बेल्ट

एक संदेश छोड़ें
उत्पाद विवरण

Driving Polyurethane Round Belt Widely used in textile , surface rough



Detailed Product Description

Industrial 12mm Polyurethane Round Belt Orange or Green for Packing Machine

Details:
(1)Thermoplastic polyurethane material, easy to be melted jointed
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35°C - 80°C
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
(6)Round Belt:
Round Belt Dia. is from 2mm to20mm
Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.
PU Round belt with reinforcement

polyurethane Round Belts Feature:

1.With excellent bend resistant

2.abrasion/wear resistant

3.easily connected

4.it's not easy to be broken at low temperature

5.fuel and oil resistant

6.anti static

polyurethane round belt Application :

1.Widely used in textile

2. printing and packing machine

3. food & beverage processing

4. wood processing

 5.paper processing

 6.electronic

 7.post service

 8.tobacco transmission line

 9.Wall floor tile conveying industrial line

10.Ceramic industry line or polishing line

Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

Dia.

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2mm 0.79 20 1.5-3% 0.3 0.7 90 A 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 A 400
4mm 1.38 35 1.5-3% 1.2 2.7 85 A  200
15mm 4.72 120 1.5-3% 17.7 39.0 85 A  30
18mm 5.71 145 1.5-3% 25.4 56.0 85 A  30
20mm 6.30 160 1.5-3% 31.3 69.0 85 A  30



Service commitment:

“Quality for keeping going ,Credit to win the world”
