Oil-Resistant Polyurethane Round Belt with Shore A 90 Hardness and Diameter 2-20mm for Drive Transmission

  • Oil-Resistant Polyurethane Round Belt with Shore A 90 Hardness and Diameter 2-20mm for Drive Transmission
न्यूनतम आदेश मात्रा 1,000
मूल्य 0.5

नि: शुल्क नमूने और कूपन के लिए मुझसे संपर्क करें।

Whatsapp:0086 18588475571

WeChat: 0086 18588475571

स्काइप: sales10@aixton.com

यदि आपको कोई चिंता है, तो हम 24 घंटे ऑनलाइन सहायता प्रदान करते हैं।

x
उत्पाद विवरण
प्रतिरूप संख्या। JN20169 प्रकार पु गोल बेल्ट
सामग्री पीयू के अंदर की सामग्री पीयू
सतह चिकनी या कठोर तन्यता ताकत 55N/मिमी2
व्यास सीमा 2 ~ 20 मिमी कठोरता 85 ए ~ 90 ए
खिंचाव दर 1.5-3% अधिकतम तन्य दर व्यास से भिन्न होता है)
कम से कम त्रिज्या 20 ~ 160 मिमी रोल -लंबाई 30 ~ 400 मीटर
फटन सामर्थ्य उच्च संपीड़न सेट कम
संघात प्रतिरोध उच्च
प्रमुखता देना

Oil-Resistant Polyurethane Round Belt

,

Shore A 90 Polyurethane V Belt

,

Diameter 2-20mm PU Round Belt
एक संदेश छोड़ें
उत्पाद विवरण
Abrasion-Resistant Polyurethane Round Belt

Our premium polyurethane round belts are designed for transmission applications in industrial machinery and product conveyance systems. These belts feature poly cord reinforcement and are available with either smooth or rough surfaces to suit various operational requirements.

Product Features
  • Exceptional abrasion resistance for extended service life
  • High tensile and tear strength for demanding applications
  • Resistant to oils, fuels, and oxygen exposure
  • Excellent weatherability and impact resistance
  • Minimal compression set for consistent performance
  • Available in multiple diameters from 2mm to 20mm
  • Compatible with various connection methods including hot press welding
Technical Specifications
Diameter Min. Bend Radius Elongation Max. Tensile Hardness Roll Length
2mm (0.79") 20mm 1.5-3% 0.3kg (0.7lbs) 95A 400m
2.5mm (0.87") 22mm 1.5-3% 0.4kg (0.9lbs) 95A 400m
3mm (0.98") 25mm 1.5-3% 0.7kg (1.6lbs) 90A 400m
3.5mm (1.18") 30mm 1.5-3% 0.95kg (2.1lbs) 90A 400m
4mm (1.38") 35mm 1.5-3% 1.2kg (2.7lbs) 90A 200m
5mm (1.57") 40mm 1.5-3% 2kg (4.3lbs) 90A 100m
6mm (1.97") 50mm 1.5-3% 3.2kg (7lbs) 90A 100m
7mm (2.17") 55mm 1.5-3% 4.1kg (9lbs) 90A 100m
8mm (2.56") 65mm 1.5-3% 5kg (11lbs) 90A 100m
9mm (2.95") 75mm 1.5-3% 6.8kg (15lbs) 90A 50m
10mm (3.94") 100mm 1.5-3% 7.7kg (17lbs) 90A 50m
12mm (3.94") 100mm 1.5-3% 12.2kg (27lbs) 90A 30m
15mm (4.72") 120mm 1.5-3% 17.7kg (39lbs) 90A 30m
18mm (5.71") 145mm 1.5-3% 25.4kg (56lbs) 90A 30m
20mm (6.3") 160mm 1.5-3% 31.3kg (69lbs) 90A 30m
Common Applications
Newspaper conveying Packaging machinery Ceramic processing Tile production Woodworking equipment Textile machinery Paper industry Food processing Grading machines
