Conveyor High Density Polyurethane Round Belt Wear Resistant

Conveyor High Density Polyurethane Round Belt Wear Resistant
Conveyor High Density Polyurethane Round Belt Wear Resistant Conveyor High Density Polyurethane Round Belt Wear Resistant Conveyor High Density Polyurethane Round Belt Wear Resistant Conveyor High Density Polyurethane Round Belt Wear Resistant

बड़ी छवि :  Conveyor High Density Polyurethane Round Belt Wear Resistant

उत्पाद विवरण:
Place of Origin: China
ब्रांड नाम: jiuna
प्रमाणन: ROHS
Model Number: Diameter 5mm~15mm
भुगतान & नौवहन नियमों:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
विस्तृत उत्पाद विवरण
tensile rate: 0.3kg-31.3kg color: green or as your require
stretching rate: 1.5%-3% material: PU
longth: 400m/roll 200m/roll 100m/roll 30m/roll hardness: 85A-90A
हाई लाइट:

pu round belt

,

पु extruded बेल्ट

Conveyor High Density Polyurethane Round Belt Wear Resistant

Detailed Product Description:

PU Cord Belt Application :

 (1) printing and packing machine

 (2) food & beverage processing

 (3) wood processing

 (4) paper processing

 (5) electronic

 (6) post service

 (7) tobacco transmission line

PU Cord Properties :

(1)Excellent abrasion resistance.

(2)Good resistance to fuel , oils and oxygen.

(3)Contains no plasticizer.

(4)Wide application temperature from -30℃~+80℃

Our company specializing in the production of PU round belt,V belt,non-slip belt,wire clip,clip wire core,PU guide, stop,package edge,skirt,scraping gum,rubber roller,wheel and all kinds of non-standard special polyurethane products.TPU proudcts characteristic and main performance are: easy adhesion,good abrasion resistance,tear resistance,bending strength,tensile strength and breaking elongation,heat-resistant moderate (-30 ℃~80℃ ) ,hardness shaw (70a~98a). Smooth round belt, V belt surface finish is good, bright color with rough surface. Uniform praticles,comfortable feel.cpu pouring product characteristics and main performance are: wear-resisting.oil,acid and alkali resistance,solvent resistance,ozone resistance,aging resistance,environmental protection,non-toxic,the main products are rubber roller plastic bags,plastic core package iron roller,printing and dyeing,etc.,and can undertake various non-standard parts processing,customized non-standard products can be according to the drawing,plastic,iron core production in a body.

transmission Round Belting :

Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

DIA

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2 0.79 20 mm 1.5-3% 0.3 0.7 90 400
3 0.98 25  mm 1.5-3% 0.7 1.6 90 400
4 1.38 35  mm 1.5-3% 1.2 2.7 85 200
5 1.57 40  mm 1.5-3% 2.0 4.3 85 100
6 1.97 50  mm 1.5-3% 3.2 7.0 85 100
7 2.17 55  mm 1.5-3% 4.1 9.0 85 100
8 2.56 65  mm 1.5-3% 5.0 11.0 85 100
9 2.95 75  mm 1.5-3% 6.8 15.0 85 50
10 2.95 75  mm 1.5-3% 7.7 17.0 85 50
12 3.94 100 mm 1.5-3% 12.2 27.0 85 30
15 4.72 120 mm 1.5-3% 17.7 39.0 85 30
18 5.71 145 mm 1.5-3% 25.4 56.0 85 30
20 6.30 160 mm 1.5-3% 31.3 69.0 85

30







Conveyor High Density Polyurethane Round Belt Wear Resistant 0Conveyor High Density Polyurethane Round Belt Wear Resistant 1
