Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line

Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line
Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line

बड़ी छवि :  Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line

उत्पाद विवरण:
Place of Origin: China
ब्रांड नाम: Jiuna
प्रमाणन: ROHS
Model Number: Diameter 10mm
भुगतान & नौवहन नियमों:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 95.000 meters per Month
विस्तृत उत्पाद विवरण
length: 50 m/roll color: orange
type: Pu smooth round belt Appl.Temp: -35/+75
Tensile Strength: 55N/mm2 Main function: Drive transmission
हाई लाइट:

पु extruded बेल्ट

,

हरे दौर बेल्ट

Industry High Density Polyurethane Timing Belts Diameter 10 mm polishing line
polyurethane round belt of  introduction:
We supply different kinds of PU V-belt, Round belt, Surper grip belt & Pentagon
Color: Orange, Red, Dark Green, Ivory, Natural  .

  • Shore Hardness:  Round belt - 87°A ± 2 .
  • Rough surface: Normal Rough / More Rough  .
  • Steel, Glass & Aramid Reinforcement on request.
  • Easily jointed with BCTech's Welding Kits
  • Features:
  • High tensile and tear strength
  • High abrasion resistance
  • Resistant to oil, grease, dust, moisture & most chemicals
  • Temperature Range: -35 ~ 85 Degrees

We offer a complete line of Polyester and Polyurethane Round belts for use in industrial machines. And In the conveyance of products ranging from transport machine,conveyor machine to glass and tile. Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers. Also can welding belt to O-ring . supply the connecting tools & Accessories for polyurethane belts , include clamp ,the Electric Iron and Knife , Connecting methods is hotpress welding , overlap welding .
The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .


Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30
