Wuxi Jiunai Polyurethane Products Co., Ltd
होम उत्पादपॉलिइरिथेन राउंड बेल्ट

High strength PU belt transmission , Good Resistance To Fuel

चीन Wuxi Jiunai Polyurethane Products Co., Ltd प्रमाणपत्र
चीन Wuxi Jiunai Polyurethane Products Co., Ltd प्रमाणपत्र
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

मैं अब ऑनलाइन चैट कर रहा हूँ

High strength PU belt transmission , Good Resistance To Fuel

High strength PU belt transmission , Good Resistance To Fuel
High strength PU belt transmission , Good Resistance To Fuel High strength PU belt transmission , Good Resistance To Fuel High strength PU belt transmission , Good Resistance To Fuel High strength PU belt transmission , Good Resistance To Fuel

बड़ी छवि :  High strength PU belt transmission , Good Resistance To Fuel

उत्पाद विवरण:
Place of Origin: China
ब्रांड नाम: Jiuna
प्रमाणन: ROHS
Model Number: Diameter2mm-20mm
भुगतान & नौवहन नियमों:
Minimum Order Quantity: 1000 meters
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
विस्तृत उत्पाद विवरण
सामग्री: पीयू प्रकार: पु दौर बेल्ट
रंग: संतरा तापमान लागू करना: -35 ℃ ~ 100 ℃
सतह: निर्बाध कठोरता: 85ए-90ए
लंबाई: 30मी/रोल प्रबलित: अनुकूलित
pre-tensioning: 1.5%-3%
हाई लाइट:

पु दौर बेल्ट

,

हरी दौर बेल्ट

,

उच्च शक्ति पु दौर बेल्ट

High strength PU belt transmission , Good Resistance To Fuel

Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30

Details:

(1)Thermoplastic polyurethane material, easy to be melted jointed

(2)Reinforced by Polyester Cord or Steel Cord

(3)Temperature range -35°C - 80°C

(4)Shore A hardness range 80A - 98A

(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics.

Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and

other industries, especially in the ceramic industry, widely used in the facilities line the glaze,

 polishing lines, and transmission line.

(6)Round Belt:

Round Belt Dia. is from 2mm to 30mm

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Application:

Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.

High strength PU belt transmission , Good Resistance To Fuel 0High strength PU belt transmission , Good Resistance To Fuel 1
