| हाई लाइट: | Reinforced cord belt,polyurethane flat belt |
||
|---|---|---|---|
OEM Reinforced polyester Kevlar Belts round With anti-abrasion
kevlar belt Feature :
1. Available in round or V-sections,
2. Low Stretch,anti-abrasion,
3. Can be cogged for increased flexibility,
4. Easily made endless with a Drive welding Kit .
Reinforced polyurethane Elevator Belting Application :
1 Any applications where non-reinforced round or V sections of polyurethane belting are stretching due to excess
loads or center distances,
2. Medium- to heavy-duty applications,
3. Conveying or diverging applications, i.e. product sizing,
4. For conveying wood, laminate, roof and ceiling tile.
5. help anchor device or Elevator pulley .
|
Item φ |
least radius of gyration
|
stretch rate |
Maximum tensile rate
|
Hardness |
length of rolled |
||
|
DIA (mm) |
In |
mm |
Stretching rate |
Kg |
Lbs |
Hardness (A) |
Roll (m) |
|
5mm |
1.57 |
40 |
1.5-3% |
2.0 |
4.3 |
85 |
100 |
|
6mm |
1.97 |
50 |
1.5-3% |
3.2 |
7.0 |
85 |
100 |
|
7mm |
2.17 |
55 |
1.5-3% |
4.1 |
9.0 |
85 |
100 |
|
8mm |
2.56 |
65 |
1.5-3% |
5.0 |
11.0 |
85 |
100 |
|
9mm |
2.95 |
75 |
1.5-3% |
6.8 |
15.0 |
85 |
50 |
|
10mm |
2.95 |
75 |
1.5-3% |
7.7 |
17.0 |
85 |
50 |
|
12mm |
3.94 |
100 |
1.5-3% |
12.2 |
27.0 |
85 |
30 |
Products introduction :
Eagle Reinforced Polyurethane Belting is 85A , 90A or 95A ,98A ,with reinforced polyurethane belt or tape for additional strength and reduced stretch, making it the ideal choice for heavy-duty conveying applications where loads cause non-reinforced belts to elongate and slip. Maybe require larger pulley diameter and the addition of take-ups to the drive system. auch as help anchor device or Elevator pulley , Excellent resistance can be to a wide range of industrial chemicals and solvents.
