85A - 90A PU Round conveyor Belt Fuels Oxygen Glass Industry

चीन Wuxi Jiunai Polyurethane Products Co., Ltd प्रमाणपत्र
चीन Wuxi Jiunai Polyurethane Products Co., Ltd प्रमाणपत्र
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

मैं अब ऑनलाइन चैट कर रहा हूँ

85A - 90A PU Round conveyor Belt Fuels Oxygen Glass Industry

85A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry
85A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry 85A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry 85A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry 85A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry

बड़ी छवि :  85A - 90A PU Round conveyor Belt Fuels Oxygen Glass Industry

उत्पाद विवरण:
Place of Origin: China
ब्रांड नाम: jiuna
प्रमाणन: ROHS
Model Number: Diameter 5mm~15mm
भुगतान & नौवहन नियमों:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
विस्तृत उत्पाद विवरण
tensile rate: 0.3kg-31.3kg color: green or as your require
stretching rate: 1.5%-3% material: PU
longth: 300m/roll 200m/roll 100m/roll hardness: 85A-90A
हाई लाइट:

pu round belt

,

पु extruded बेल्ट

85A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry

PU Cord Belt Application :

 (1)printing and packing machine

 (2)food & beverage processing

 (3)wood processing

 (4)paper processing

 (5) electronic

 (6)post service

 (7)tobacco transmission line

PU Cord Properties :

(1)Excellent abrasion resistance.

(2)Good resistance to fuel , oils and oxygen.

(3)Contains no plasticizer.

(4)Wide application temperature from -30℃~+80℃

transmission Round Belting Feature :

 (1)   With excellent bend resistant

 (2)   wear resistant

 (3)  easy connected

 (4)    t's not easy to be broken at low temperature

Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

DIA

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2 0.79 20 mm 1.5-3% 0.3 0.7 90 400
3 0.98 25  mm 1.5-3% 0.7 1.6 90 400
4 1.38 35  mm 1.5-3% 1.2 2.7 85 200
5 1.57 40  mm 1.5-3% 2.0 4.3 85 100
6 1.97 50  mm 1.5-3% 3.2 7.0 85 100
7 2.17 55  mm 1.5-3% 4.1 9.0 85 100
8 2.56 65  mm 1.5-3% 5.0 11.0 85 100
9 2.95 75  mm 1.5-3% 6.8 15.0 85 50
10 2.95 75  mm 1.5-3% 7.7 17.0 85 50
12 3.94 100 mm 1.5-3% 12.2 27.0 85 30
15 4.72 120 mm 1.5-3% 17.7 39.0 85 30
18 5.71 145 mm 1.5-3% 25.4 56.0 85 30
20 6.30 160 mm 1.5-3% 31.3 69.0 85

30





85A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry 085A - 90A PU Round conveyor Belt  Fuels Oxygen Glass Industry 1
